Ascent X2 – Cellular Multi-Tenant Entry System with Directory Insert

Model 16-X2

Control up to two gates or doors and grant access via app, text, voice, keypad, directory call, or Wiegand device!

The Boost You Need

Spec Sheet: Ascent X2 (16-X2) – Cellular Multi-Tenant Telephone Entry System with Keypad

Directory Templates:  5 Residents | 10 Residents | 20 Residents

Quick Start Guide: Ascent X2

Wiring Guide: Wiegand Device to Ascent

Product Info

Our cellular multi-tenant entry systems are backed by 4G LTE cellular technology and are powered by our simple, cloud-based Summit Control software platform.

Ascent X2 is designed for apartments, gated communities, or businesses, and can handle up to 30 residents. It features a directory with user-printable inserts. It is a great choice for replacing aging, antiquated multi-tenant entry systems.

This unit features app, text, and voice control as well as back-to-back calling of up to 3 phone numbers.


  • Directory panel for user-printed inserts
  • 4G LTE cellular
  • High-definition Ascent Camera for still photos
  • Photo push notifications
  • 2 Wiegand inputs
  • Ascent Link integration
  • Control via 6 different control methods
  • Control up to 2 gates/doors
  • Cloud-based access-control management
  • Up to 10,000 app, text, and voice users
  • Up to 1,000 keypad codes
  • Configurable keypad code length (4 to 6 digits)
  • Rollover calling—up to 3 phone numbers per address
  • Push and/or email event and status notifications

Other Great Features

  • 7-day timers
  • Holiday timers
  • Special-event timers
  • Audit trail with detailed reports
  • “Do Not Disturb” mode
  • Drop-in directory insert
  • Durable acrylic directory lens
  • Stainless-steel faceplate
  • Powder-coated-steel enclosure
  • Nightlight, backlit keypad, and valet light

Calling Made Easy
Key in the directory code listed next to the resident you wish to call and the unit calls.

An Ascent with a View
Get visual ID on all visitors to your property with photo push notifications; get photos automatically or whenever you choose.

Powerfully Expandable
Network multiple Ascent units together and manage multiple entries via Summit Control.

Get Connected Every Time
Assign multiple phone numbers to each address to be called one after the other, ensuring a connection is always made.

Powered by Summit Control­™

Unit includes a GSM SIM card ready for activation.

Two-Year Limited Warranty

Made in the USA from Global Materials

Always complete a site survey to make sure you have cellular coverage. Our cellular products run on the 4G LTE network.
This is a cellular accessory for a gate/door, so an uninterrupted cellular connection cannot be guaranteed.
An emergency egress or primary entry mechanism should always be used (transmitter, fire box, mechanical release).
Consult with your dealer, distributor, and/or system designer for more information.
